Overview

The following are the technical specifications for the spectrum+ steel playground equipment product range.

spectrum+ Specifications

Main Uprights
75 x 75 x 2.5mm galvanised RHS with powder coat finish.
Upgraded to 75 x 75 x 3.0mm in high load locations.

Platform Decks
3.0mm galvanised steel sheet, punched dimple pattern and slip resistant powder coat.

Roofs
Powder coated galvanised sheet steel, corrugated steel sheeting or rotomoulded plastic as specified.

Safety Railing
900mm high guardrail panels on platforms over 500mm.
Powder coated galvanised steel tube or HDPE plastic panels as specified.

Handgrips
27mm O/D galvanised steel tube with powder coat finish.
Supplied at climbing access points as appropriate.
Access ladders include 27mm O/D handgrip integrated in ladder side.

Handrails
34mm O/D galvanised steel tube with powder coat finish.

Play Components
Fabricated from galvanised steel, welds treated with zinc rich primer – powder coat finish.

Slides
Heavy duty reinforced fibreglass, rotomoulded plastic or stainless steel as specified.

Tunnels
Powder coated galvanised steel tube with end panels.

Activity Panels
Rotomoulded plastic beads or HDPE plastic sheet panels as appropriate.

Climbing Ropes
Synthetic strands braided over a galvanised steel wire core.

Hardware
Trilobial taptite bolts, cup head bolts, recessed safety nuts, screws – vandal resistant with galvanised/class 3 finish.

Footings
Concrete to a minimum depth of 500mm with earth hard packed to mouth of hole.

spectrum+ junior Specifications

Main Uprights
65 x 65 x 2.5mm galvanised RHS with powder coat finish.

Platform Decks
2.0mm galvanised steel sheet, punched dimple pattern and slip resistant powder coat.

Roofs
Powder coated galvanised sheet steel, corrugated steel sheeting or rotomoulded plastic as specified.

Safety Railing
750mm high guardrail panels on platforms over 500mm.
Powder coated galvanised steel tube or HDPE plastic panels as specified.

Handgrips
27mm O/D galvanised steel tube with powder coat finish.
Supplied at climbing access points as appropriate.

Handrails
34mm O/D galvanised steel tube with powder coat finish.

Play Components
Fabricated from galvanised steel, welds treated with zinc rich primer – powder coat finish.

Slides
Heavy duty reinforced fibreglass, rotomoulded plastic or stainless steel as specified.

Tunnels
Powder coated galvanised steel tube with end panels.

Activity Panels
Rotomoulded plastic beads or HDPE plastic sheet panels as appropriate.

Climbing Ropes
Synthetic strands braided over a galvanised steel wire core.

Hardware
Trilobial taptite bolts, cup head bolts, recessed safety nuts, screws – vandal resistant with galvanised/class 3 finish.

Footings
Concrete to a minimum depth of 500mm with earth hard packed to mouth of hole.

spectrum+ hybrid Specifications

Main Uprights
75 x 75 x 2.5mm galvanised RHS with powder coat finish.
Upgraded to 75 x 75 x 3.0mm in high load locations.

Platform Decking
120 x 35mm (nominal) White Cypress, sawn finish, corners radiused and fully screwed.

Platform Bearers
125 x 60mm sawn White Cypress with corners radiused.

Timber Finish
Natural White Cypress or ‘Quantum Timbre Plus’ coating available for visual enhancement.

Roofs
Powder coated galvanised sheet steel, corrugated steel sheeting or rotomoulded plastic as specified.

Safety Railing
900mm high guardrail panels on platforms over 500mm.
Powder coated galvanised steel tube, sawn White Cypress or HDPE plastic panels as specified.

Handgrips
27mm O/D galvanised steel tube with powder coat finish.
Supplied at climbing access points as appropriate.
Access ladders include 27mm O/D handgrip integrated in ladder side.

Handrails
34mm O/D galvanised steel tube with powder coat finish.

Play Components
Fabricated from galvanised steel, welds treated with zinc rich primer – powder coat finish.

Slides
Heavy duty reinforced fibreglass, rotomoulded plastic or stainless steel as specified.

Tunnels
Powder coated galvanised steel tube with end panels.

Activity Panels
Rotomoulded plastic beads or HDPE plastic sheet panels as appropriate.

Climbing Ropes
Synthetic strands braided over a galvanised steel wire core.

Hardware
Trilobial taptite bolts, cup head bolts, recessed safety nuts, screws – vandal resistant with galvanised/class 3 finish.

Footings
Concrete to a minimum depth of 500mm with earth hard packed to mouth of hole.

spectrum+ max Specifications

Main Uprights
75 x 75mm aluminium with powder coat finish.

Platform Decking
Aluminium sheet with punched dimple pattern and slip resistant powder coat.

Roofs
Primed and powder coated pre-galvanised sheet steel, corrugated steel sheeting or rotomoulded plastic as specified.

Safety Railing
900mm high guardrail panels on platforms over 500mm.
Primed and powder coated pre-galvanised steel tube or HDPE plastic panels as specified.

Handgrips
27mm O/D pre-galvanised steel tube with primed and powder coated finish.
Supplied at climbing access points as appropriate.
Access ladders include 27mm O/D handgrip integrated in ladder side.

Handrails
34mm O/D galvanised steel tube with primed and powder coated finish

Play Components
Fabricated from pre-galvanised steel, welds treated with zinc rich primer – primed and powder coated finish.

Slides
Heavy duty reinforced fibreglass, rotomoulded plastic or stainless steel as specified.

Tunnels
Primed and powder coated galvanised steel tube with end panels.

Activity Panels
Rotomoulded plastic beads or HDPE plastic sheet panels as appropriate.

Climbing Ropes
Synthetic strands braided over a galvanised steel wire core.

Hardware
Vandal resistant 316 stainless steel fasteners.

Footings
Concrete to a minimum depth of 500mm with earth hard packed to mouth of hole.

Powder Coat Primer Layer
A zinc rich powder coat primer base layer is applied to all galvanised steel components.Download PDF
